极思芯Gigastech 全系列原厂直销可技术支持

发布日期：2024-01-18~~类别：会员资讯~~ 阅读：1252

摘要：极思芯Gigastech是一家拥有强大自主设计能力的公司，从事节能型功率半导体器件和集成电路的研发与销售。公司拥有数名研究生和博士，研发团队主要毕业于国内外顶尖院校，依托半导体精英团队和仪

Product Name	Package	Polarity	Vds(max)(V)	VGS(V)	ID @ TC=25°C max(A)	ESD Diode	RDS (on) @10V typ(mΩ)	RDS (on) @10V max(mΩ)	RDS (on) @4.5V typ(mΩ)	RDS (on) @4.5V max(mΩ)	RDS (on) @2.5V typ(mΩ)	RDS (on) @2.5V max(mΩ)	VGS(th) typ(V)
GTM20P065M	SOT-723	P	-20	±10	-0.66	ESD	—	—	360	520	500	700	-0.65
GTM20P065A	SOT-523	P	-20	±10	-0.66	ESD	—	—	360	520	500	700	-0.65
GTM2N7002T	SOT-523	N	60	±20	0.34	ESD	2000	2500	2500	3500	—	—	1.5
GTM20N075A	SOT-523	N	20	±10	0.75	ESD	—	—	250	380	350	450	0.65
GTM20N4E3N	SOT-323	N	20	±12	2.2	/	—	—	45	58	68	110	0.75
GTM20P4E3N	SOT-323	P	-20	±12	-1.4	/	—	—	109	128	148	175	-0.7
GTM2300B	SOT-23	N	20	±12	3	/	—	—	40	50	45	80	0.75
GTM2300A	SOT-23	N	20	±12	4	/	—	—	26	30	37	45	0.6
GTM2312A	SOT-23	N	20	±12	4.5	/	—	—	14	22	20	35	1.2
GTM3400A	SOT-23	N	30	±12	5	/	28	35	31	40	45	50	0.9
GTM3404A	SOT-23	N	30	±20	5.8	/	26	31	36	43	—	—	1.6
GTM2N7002	SOT-23	N	60	±20	0.1	ESD	2000	3000	3000	4000	—	—	1.2
GTM2301B	SOT-23	P	-20	±8	-2.8	/	—	—	105	130	145	190	-0.65
GTM2301A	SOT-23	P	-20	±12	-3	/	—	—	70	90	85	120	-0.65
GTM3415A	SOT-23	P	-20	±8	-4	ESD	—	—	38	48	48	65	-0.55
GTM2305A	SOT-23	P	-20	±12	-4	/	—	—	38	50	46	60	-0.7
GTM2305B	SOT-23	P	-20	±10	-4.2	/	—	—	28	38	38	50	-0.68
GTM3401A	SOT-23	P	-30	±12	-4.2	/	48	55	56	75	72	90	-1
GTM3407A	SOT-23	P	-30	±20	-4.1	/	38	50	60	100	—	—	-1.6
GTM1508L	SOT23-3L	P	-15	±12	-8	/	—	—	13	18	20	26	-0.7
GTM1807L	SOT23-3L	P	-15	±12	-7	/	—	—	23	30	28	38	-0.5
GTM20P08A	SOT23-3L	P	-20	±12	-8	/	—	—	15	18	21	28	-0.7
GTM2005L	SOT23-3L	P	-20	±10	-5	/	—	—	30	38	40	50	-0.68
GTM2007L	SOT23-3L	P	-20	±12	-6.5	/	—	—	19	25	25	30	-0.7
GTM2321L	SOT23-3L	N	19.5	±12	6	/	8	10	11	13	14	20	0.7
GTM3400L	SOT23-3L	N	30	±12	5.8	/	28	35	31	40	45	50	0.9
GTM18P08A3L	SOT23-3L	P	-12	±12	-8	/	—	—	14	18	20	28	-0.68
GTM18P08B3L	SOT23-3L	P	-12	±12	-8	/	—	—	15	18	20	25	-0.68
GTM3415L	SOT23-3L	P	-20	±8	-4.2	ESD	—	—	38	48	48	65	-0.55
GTM2021L	SOT23-3L	P	-20	±12	-7	/	—	—	18	23	22	32	-0.7
GTM2023L	SOT23-3L	P	-20	±12	-6	/	—	—	18	23	23	32	-0.45
GTM2025L	SOT23-3L	P	-20	±12	-6	/	—	—	20	25	27	35	-0.7
GTM2305L	SOT23-3L	P	-20	±12	-4.2	/	—	—	38	50	46	60	-0.7
GTM3401L	SOT23-3L	P	-30	±12	-4.2	/	48	55	56	75	72	90	-1
GTM3407L	SOT23-3L	P	-30	±20	-4.3	/	38	50	60	100	—	—	-1.6
GTM8205S	SOT23-6L	N+N	20	±12	4	/	—	—	20	27	25	37	0.7
GTM2003A	SOT23-6L	N+P	20	±12	3	/	—	—	28	35	36	55	0.75
GTM2003A	SOT23-6L	N+P	-20	±12	-3	/	—	—	60	75	81	100	-0.7
GTM20N16A	DFN2*2-6L	N	20	±12	16	/	—	—	11	12	13	18	0.7
GTM12P16A	DFN2×2-6L	P	-15	±12	-16	/	—	—	14	16	20	23	-0.67
GTM15P16A	DFN2×2-6L	P	-15	±12	-16	/	—	—	13	17	20	26	-0.7
GTM18P16C6N	DFN2*2-6L	P	-12	±12	-16	/	—	—	14	18	18	24	-0.7
GTM18P18C6N	DFN2*2-6L	P	-12	±12	-16	/	—	—	12	16	16	17	-0.7
GTM20P18C6N	DFN2*2-6L	P	-20	±12	-16	/	—	—	12	15	15	18	-0.7
GTM20P15A	DFN2×2-6L	P	-20	±12	-15	/	—	—	16	20	22	26	-0.7
GTM20P17A	DFN2*2-6L	P	-20	±12	-17	/	10	14	12	16	17	24	-0.65
GTM2007D	DFN2*2-6L	P+P	-20	±12	-7	/	—	—	33	45	45	60	-0.7
GTMQ2012D	DFN2X3-6L	N+N	20	±12	12	/	—	—	7.3	8	9.2	10.5	0.7
GTMQ20D18	DFN3*3	N+N	20	±10	55	/	—	—	5.5	6.8	7	9.5	0.7
GTMQ20D20	DFN3*3	N+N	19	±10	55	ESD	—	—	3.2	5	3.9	6	0.7
GTMQ30D26A	DFN3*3	N+N	30	±20	26	/	7.8	10	11.6	16	—	—	1.5
GTMQ30D50A	DFN3*3	N+N	30	±20	20	/	22	32	32	50	—	—	1.5
GTMQ1680A	PDFN3.3*3.3	N	18	±12	80	/	—	—	2	2.5	3.5	5	0.65
GTMQ20N60A	PDFN3.3*3.3	N	20	±12	60	/	2.3	3	2.5	3.2	3.2	4	0.7
GTMQ3016A	PDFN3.3*3.3	N	30	±20	16	/	11	16	16	25	—	—	1.5
GTMQ3026A	PDFN3.3*3.3	N	30	±20	26	/	7.8	10	11.6	15	—	—	1.5
GTMQ3056A	PDFN3.3*3.3	N	30	±20	56	/	5.5	6.3	8.4	9	—	—	1.7
GTMQ3040A	PDFN3.3*3.3	N	30	±20	40	/	6.5	8.5	11	14	—	—	1.7
GTMQ3080A	PDFN3.3*3.3	N	30	±20	80	/	4.2	5.8	6.3	8	—	—	1.5
GTMQ3082A	PDFN3.3*3.3	N	30	±20	82	/	3	4.3	5	6.8	—	—	1.6
GTMQ30120A	PDFN3.3*3.3	N	30	±20	120	/	1.2	1.8	2	2.4	—	—	1.5
GTMQ4054A	PDFN3.3*3.3	N	40	±20	54	/	5	6.5	7	10.5	—	—	1.6
GTMQ2027B	PDFN3.3*3.3	P	-18	±12	-27	/	8.8	13	10.3	15	13.1	18	-0.65
GTMQ2027A	PDFN3.3*3.3	P	-20	±12	-27	/	11	13	12	15	15	18	-0.65
GTMQ2045A	PDFN3.3*3.3	P	-20	±12	-55	/	5.5	8.5	6.5	9	8.5	10	-0.6
GTMQ2045B	PDFN3.3*3.3	P	-20	±12	-45	/	—	—	12	15	15	18	-0.65
GTMQ2055A	PDFN3.3*3.3	P	-20	±12	-55	/	4.7	6.8	5.5	7	7.1	10	-0.65
GTMQ2055B	PDFN3.3*3.3	P	-20	±12	-55	/	4	5.5	4.7	6	6.2	8	-0.68
GTMQ2057A	PDFN3.3*3.3	P	-20	±12	-55	/	3.5	5.5	4.1	6	5.1	8	-0.68
GTMQ4435A	PDFN3.3*3.3	P	-30	±20	-10	/	17	23	24	33	—	—	-1.7
GTMQ4407A	PDFN3.3*3.3	P	-30	±20	-12	/	8	12	10	15	—	—	-1.4
GTMQ3015A	PDFN3.3*3.3	P	-30	±25	-15	/	14	18	20	28	—	—	-1.5
GTMQ3033A	PDFN3.3*3.3	P	-30	±20	-33	/	10.5	14	15	20	—	—	-1.5
GTMQ3083A	PDFN3.3*3.3	P	-30	±20	-50	/	6.5	11	9.2	15	—	—	-1.5
GTMQ3061A	PDFN3.3*3.3	P	-30	±20	-61	/	6	7.5	9.3	12.5	—	—	-1.6
GTMQ4045A	PDFN3.3*3.3	P	-40	±20	-40	/	10	12	13	16	—	—	-1.7
GTMQ3010D	PDFN3.3*3.3	N+N	30	±20	22	/	13	16	19	35	—	—	1.5
GTMQ3010DB	PDFN3.3*3.3	N+N	30	±20	40	/	6.3	8	9.5	13	—	—	1.7
GTMQ3020D	PDFN3.3*3.3	N+N	30	±20	40	/	6.5	8.5	11	14	—	—	1.7
GTMQ3020DB	PDFN3.3*3.3	N+N	30	±20	40	/	6.3	8	9.5	13	—	—	1.7
GTMV3015D	PDFN5*6	P+P	-30	±25	-15	/	10	12	15	19	—	—	-1.4
GTMV30D56A	PDFN5*6	N+N	30	±20	56	/	5.5	6.3	8.4	9	—	—	1.7
GTMV40D40	PDFN5*6	N+N	40	±20	40	/	6	7.5	9	11	—	—	1.5
GTMV4020D	PDFN5*6	N+N	40	±20	40	/	7.1	8	11	13	—	—	1.8
GTMV25140A	PDFN5*6	N	25	±20	140	/	2	2.4	3	3.6	—	—	1.6
GTMV3040A	PDFN5*6	N	30	±20	40	/	7	9	10	15	—	—	1.5
GTMQ3058A	PDFN5*6	N	30	±20	58	/	5	6	6.9	9	—	—	1.7
GTMV30N80A	PDFN5*6	N	30	±20	80	/	3.6	4.8	4.7	7.1	—	—	1.5
GTMV3090A	PDFN5*6	N	30	±20	90	/	3	4.8	4.7	7.3	—	—	1.5
GTMV3082A	PDFN5*6	N	30	±20	82	/	3	4.3	5	6.8	—	—	1.6
GTMV3086A	PDFN5*6	N	30	±20	86	/	3.2	5	5.6	7	—	—	1.5
GTMV3086B	PDFN5*6	N	30	±20	86	/	4.6	5	6.8	9	—	—	1.5
GTMV30100A	PDFN5*6	N	30	±20	100	/	2.6	3.2	4	6	—	—	1.5
GTMV30110A	PDFN5*6	N	30	±20	110	/	2.6	3.5	3.8	4.9	—	—	1.6
GTMV30120A	PDFN5*6	N	30	±20	120	/	1.6	2.2	2.4	3.2	—	—	1.8
GTMV30130A	PDFN5*6	N	30	±20	130	/	1.5	1.8	2.4	3.1	—	—	1.7
GTMV30150A	PDFN5*6	N	30	±20	150	/	1.5	2	1.8	2.2	2.5	3.2	0.65
GTMV30160A	PDFN5*6	N	30	±20	160	/	1	1.4	1.5	2.1	—	—	1.7
GTMQ3002A	PDFN5*6	N	30	±20	130	/	1.3	2	2.2	4	—	—	1.6
GTMV4030A	PDFN5*6	N	40	±20	30	/	10.5	12.5	15	19	—	—	1.6
GTMQ4038A	PDFN3.3*3.3	N	40	±20	38	/	6.1	7	10	11	—	—	1.8
GTMV4040A	PDFN5*6	N	40	±20	40	/	7.5	9.5	10.5	13.5	—	—	1.6
GTMV4052A	PDFN5*6	N	40	±20	52	/	5	6	7.5	10	—	—	1.7
GTMV4056A	PDFN5*6	N	40	±20	56	/	4.7	6.5	7.5	10.5	—	—	1.6
GTMV4070A	PDFN5*6	N	40	±20	70	/	4.4	6	6	13	—	—	1.5
GTMV4080A	PDFN5*6	N	40	±20	105	/	2.7	3.5	3.8	5.4	—	—	1.6
GTMV4090A	PDFN5*6	N	40	±20	90	/	2.2	2.5	3	3.6	—	—	1.6
GTMV4504A	PDFN5*6	N	45	±20	130	/	2.3	4	3.4	6	—	—	1.7
GTMV6040A	PDFN5*6	N	60	±20	40	/	14.5	16	18	26	—	—	1.6
GTMV6050A	PDFN5*6	N	60	±20	50	/	12	15	14.5	18	—	—	1.6
GTMV6080A	PDFN5*6	N	60	±20	80	/	4.8	6.2	6.9	9	—	—	1.7
GTMV60130A	PDFN5*6	N	60	±20	130	/	2.2	3	3	4.1	—	—	1.6
GTMV6880A	PDFN5*6	N	68	±25	80	/	6	8	—	—	—	—	3
GTMV8080A	PDFN5*6	N	80	±20	80	/	5.5	8	9	15	—	—	2
GTMV80100A	PDFN5*6	N	80	±20	100	/	3.7	4.8	5.5	7	—	—	2
GTMV10S60A	PDFN5*6	N	100	±20	60	/	8	10	11	15	—	—	2.2
GTMV10S70A	PDFN5*6	N	100	±20	70	/	7	8	8	11	—	—	1.8
GTMV10S80A	PDFN5*6	N	100	±20	80	/	4.5	5.8	5.5	6.8	—	—	1.8
GTMV10S130A	PDFN5*6	N	100	±20	130	/	2.7	3.5	3.5	4.5	—	—	1.6
GTMV10S140A	PDFN5*6	N	100	±20	130	/	2.7	3.5	3.5	4.5	—	—	2.7
GTMV12S126A	PDFN5*6	N	120	±20	126	/	5.8	6.8	—	—	—	—	3
GTMQ2070A	PDFN5*6	P	-20	±10	-70	/	—	—	2.2	3	3	4	-0.65
GTMQ2070B	PDFN5*6	P	-20	±10	-70	/	—	—	2	3	2.8	4	-0.65
GTMV2069A	PDFN5*6	P	-20	±12	-69	/	—	—	2.7	4.2	3.6	6	-0.65
GTMV2069B	PDFN5*6	P	-20	±12	-69	/	—	—	2.8	3.2	3.6	4	-0.65
GTMQ2071A	PDFN5*6	P	-20	±12	-71	/	2.6	3.6	2.9	4	3.6	5	-0.65
GTMV3081A	PDFN5*6	P	-30	±20	-55	/	6.5	9	8.2	12	—	—	-1.5
GTMV4021A	PDFN5*6	P	-40	±20	-20	/	25	33	33	42	—	—	-1.6
GTMV4035A	PDFN5*6	P	-40	±20	-35	/	14	20	20	30	—	—	-1.6
GTMV4045A	PDFN5*6	P	-40	±25	-45	/	8	10	10	15	—	—	-1.6
GTMV3066NP	PDFN5*6	N+P	30	±20	20	/	11	16	17.7	25	—	—	1.7
GTMV3066NP	PDFN5*6	N+P	-30	±20	-15	/	16.6	23	24.2	33	—	—	-1.7
GTM8205A	TSSOP-8	N+N	20	±12	7	/	—	—	21	28	25	38	0.65
GTMS4406A	SOP-8	N	30	±20	20	/	6.5	8.5	11	14	—	—	1.7
GTMS3012A	SOP-8	N	30	±20	12	/	6.2	9	8.2	11	—	—	1.5
GTMS4435A	SOP-8	P	-30	±25	-10	/	16	20	26	32	—	—	-1.7
GTMS3011A	SOP-8	P+P	-30	±20	-12	/	14	18	20	28	—	—	-1.5
GTMS4407A	SOP-8	P	-30	±20	-12	/	12	15	17	22	—	—	-1.5

GTMS4011S	SOP-8	P	-40	±20	-11	/	14.5	20	20.3	30	—	—	-1.6
GTM9926A	SOP-8	N+N	20	±10	6	/	—	—	20	28	26	37	0.7
GTMS4805D	SOP8	P+P	-25	±20	-9	/	18	22	23	30	—	—	-1.6
GTM4953A	SOP-8	P+P	-30	±20	-5.1	/	43	55	62	90	—	—	-1.6
GTM4606A	SOP-8	N+P	30	±20	6	/	18.6	22	30	37	—	—	1.55
GTM4606A	SOP-8	N+P	-30	±20	-6	/	27	35	42	50	—	—	-1.32
GTMS4614A	SOP-8	N+P	40	±20	8	/	17	22	22	28	—	—	1.5
GTMS4614A	SOP-8	N+P	-40	±20	-6	/	33	42	41	50	—	—	-1.5
GTM4503A	SOP-8	N+P	-30	±20	-9.1	/	16	20	21	35	—	—	-1.5
GTM4503A	SOP-8	N+P	30	±20	10	/	7.5	13.5	13	20	—	—	1.6
GTM30N05C	TO-220	N	30	±20	90	/	3.3	4.5	5.5	8	—	—	1.5
GTMJ6082A	TO-220C	N	60	±20	80	/	5.5	7.6	9	12	—	—	2.7
GTME2060A	TO-252-2L	N	20	±12	60	/	—	—	3.5	5	7	10	0.7
GTME2060K	TO-252-2L	N	20	±12	60	/	—	—	4.8	6.3	6.2	9.4	0.7
GTME3006NP	TO-252-2L	N	30	±20	25	/	14	25	36	40	—	—	1.5
GTME3006NP	TO-252-2L	P	-30	±20	-18	/	38	40	53	60	—	—	-1.5
GTME3080A	TO-252-2L	N	30	±20	80	/	4.9	6.5	7.5	10	—	—	1.5
GTME3082A	TO-252-2L	N	30	±20	82	/	3	4.8	4.7	7.3	—	—	1.6
GTME30100A	TO-252-2L	N	30	±20	100	/	3	4.8	4.8	7.3	—	—	1.6
GTME30120A	TO-252-2L	N	30	±20	120	/	2.5	3	4	6	—	—	1.5
GTME4002A	TO-252-2L	N	40	±20	80	/	1.9	3	3.6	6	—	—	2.9
GTME4080A	TO-252-2L	N	40	±20	120	/	3.2	4.3	4.5	5.4	—	—	1.6
GTME4504A	TO-252-2L	N	45	±20	130	/	3	4	5	6	—	—	1.8
GTME6020A	TO-252-2L	N	60	±20	23	/	20	22	23	30	—	—	1.5
GTME6040A	TO-252-2L	N	60	±20	40	/	14	16	18	26	—	—	1.6
GTME6050A	TO-252-2L	N	60	±20	50	/	12	15	14.5	18	—	—	1.6
GTME6080A	TO-252-2L	N	60	±20	80	/	4.8	6.2	6.5	9	—	—	1.7
GTME6027A	TO-252-2L	P	-60	±20	-40	/	20	25	26	32	—	—	-1.8
GTME10S21A	TO-252-2L	P	-100	±20	-21	/	45	55	55	65	—	—	-2
GTMG6080A	TO-263-2L	N	60	±20	80	/	5	7.6	8	12	—	—	2.7
GTMG6090A	TO-263-2L	N	60	±20	90	/	2.2	2.5	—	—	—	—	2.8
GTMG60100A	TO-263-2L	N	60	±20	100	/	1.8	2.3	—	—	—	—	2.8
GTMG85N146A	TO-263-2L	N	85	±20	146	/	4.8	5.9	—	—	—	—	2.8
GTMG85N160A	TO-263-2L	N	85	±20	160	/	5	5.4	—	—	—	—	3
GTMG10S110A	TO-263-2L	N	100	±20	110	/	4.1	5.1	—	—	—	—	2.8
GTMG10S150A	TO-263-2L	N	100	±20	150	/	3.7	4.3	—	—	—	—	3
GTMT40N100A	TOLL	N	40	±20	150	/	2.0	2.5	2.7	3.6	—	—	1.6
GTMT40N150A	TOLL	N	40	±20	280	/	1.2	1.6	1.6	2.1	—	—	1.6
GTMT40N160A	TOLL	N	40	±20	300	/	1.1	1.3	1.4	1.7	—	—	1.7
GTMT60N100A	TOLL	N	60	±20	100	/	1.3	1.6	—	—	—	—	2.8
GTMT60N350A	TOLL	N	100	±20	350	/	1.6	1.9	—	—	—	—	3
GTMT85N120A	TOLL	N	85	±20	120	/	1.3	1.8	—	—	—	—	2.8
GTMT85N210A	TOLL	N	85	±20	210	/	2	2.3	—	—	—	—	3.5
GTMT10S120A	TOLL	N	100	±20	308	/	1.6	2.2	—	—	—	—	2.8
GTMT10S210A	TOLL	N	100	±20	210	/	2	2.3	—	—	—	—	3.5
GTMT10S400A	TOLL	N	100	±20	400	/	1.1	1.4	—	—	—	—	3.5
